Quick Details

  • Place of Origin: China (Mainland)
  • Brand Name: TOPSFLO
  • Model Number: TM30A-A
  • Theory: Vacuum Pump
  • Structure: Diaphragm Pump
  • Usage: Air Pump
  • Power: Electric
  • Standard or Nonstandard: Standard
  • Fuel: DC power, Battery
  • Pressure: High Pressure
  • Application: Gas transferring and evacuating, Industrial pressure and vacuum applications
  • Certificate: CE,RoHS, ISO9001
  • Working way: Continuous or intermittent work
  • Max flow: 6L/min.
  • Motor: DC brush, brushless, coreless brushless
  • Materials: pump head Nylon, membrane EPDM / PTFE, valve EPDM / FPM
  • Voltage: 6,12,24V.
  • Lifetime: 15000hour,10000hour,3000hour.
  • More Features: High efficiency, Can be mounted in any place, DC an DCB models
  • Features: Oil-free,Compact size, Corrosionresistant, Maintenance Free, Long life

Packaging & Delivery

Packaging Details Inner box in firm carton,protected by pallets;Stand export packing,or OEM packing.
Delivery Time 25

High Performance 6V 12V 24V Gas Pump

Product Description



Product Specification



ModelPressure PumpVacuum PumpRated VoltageNo-load CurrentMax PressureMax VacuumMax Flow
 (Item Number)(Item Number)(Vdc)(A)(KPa)(KPa)(L/min)
TM30A-A       TM30A-A12-    P12006   TM30A-A12-V7006     6 /12 / 240.4/0.24/0.15120-706
 " P " means pressure pump,  " V " means vacuum pump, "6/12/24" means different voltages optional.
Pump Weight:220g;   Pump Size:80mm*31mm*58mm;  Inlet&Outlet:OD 4.8mm/ID 2.6mm,hose suggestion:ID 4.0mm
Super silent noise<50dB from 1 Meter;  Materials:pump head Nylon, membrane EPDM / PTFE, valve EPDM / FPM
Motor type and code:“A”:premium duty brush DC motor (reference lifetime 3,000hours),longer endurance lifetime than other normal DC membrane pump




  • Highest Performance/Size Ratio

  Innovative and efficient engineering designs enable the TM30A Series to push the performance envelope in a lightweight, compact size.

  • Performs Quieter

  Optimized head, chamber, and flow path reduce noise without compromising performance.

  • Lasts Reliably Longer

  Using the advanced diaphragm elastomer and superior brushless motor design sets the highest benchmark for service-free     operation that exceeds 10,000 hours.

  • Uncontaminated flow

  No contamination of the media due to oil-free operation

  • Little vibration

  Because of leading edge technologies, top quality bearing, superior brushless motor

  • High level of gas tightness

  Thanks to stress-optimised structured diaphragm, newly-designed valves and sealing systems, precise placement of the pump head

  • Extreme chemical resistance

  The use of chemically resistant materials optional such as PTFE FKM or other material combinations for the parts which    allows the corrosive gas to be pumped.

  • Optimal solution for your application

  A wide standard range of materials, motors , voltages configurates multiple components system selected







   1. Industrial pressure and vacuum applications         2. Portable Analytical Instruments            3. Medical Diagnostic Equipment
   4. Air Quality Sampling Monitors            5. Respiration Monitors          6. Gas or Odor Leak Detectors
etc..












More About Products

Micro diaphragm air pump/ vacuum pump TM series
