Quick Details

  • Place of Origin: China (Mainland)
  • Brand Name: TOPSFLO
  • Model Number: TD5, Solar Water Pump
  • Theory: Centrifugal Pump
  • Structure: Single-stage Pump
  • Usage: Water
  • Power: Electric
  • Standard or Nonstandard: Standard
  • Fuel: Solar panel, Battery, DC power
  • Pressure: High Pressure
  • Application: Solar water heaters, Hot Water Circulation, Solar Applications Liquid Transfer
  • Temperature range: 0~110 Celsius degree
  • Certificate: CE,RoHS, FDA,ISO9001
  • Motor: DC brushless motor
  • Max Pressure: 10 Bar
  • Liquid: hot water circulating
  • Life time: 30000 hours
  • Voltage range: 6V DC ~ 24VDC
  • Start power: less than 2 Watt..

Packaging & Delivery

Packaging Details 50 Inner boxes in firm carton,protected by pallets;Stand export packing,or OEM packing.
Delivery Time 7~25



Professional Supplier of Solar Pump/Solar DC Pump/Solar Water Pump

Product Description



TD5 is the specialized solar pump series newly developed based on our TS5 pump.



TOPSFLO TD5 pump is currently the world's only all-stainless steel solar hot water circulating pump, made of food grade stainless steel, very safe and reliable, always protect your family's health, food grade stainless steel is healthy and safe metal to our people, acid resistant, no dangerous element exudation, the medical equipment and food machinery widely used is the best example.











1. Directly connects to photovoltaic panel, start-up power requires less than 2 Watt
2. Ideal 5W, 10W, 15W, 25W power consumption optional for different sizes SWH systems
3. The exclusive food grade stainless steel solar DC hot water pump,keep far away Plumb danger more safe, protect your families' health
4. Operates on safe DC power, you will not expose yourself to hazardous grid power voltage
5. High efficient ECM brushless DC motor, ideal long life time 30000 hours
6. Advanced magnetic drive technology for static-seal,without any leakage for ever
7. Can run with hot water (230° F) and at high pressure(145 Psi)









TD5 is the most advanced pump we developed for solar hot water heating system, which is similar to the SID & Laing D5 pumps from US. It's max flow rate and max water head reach 25L/Min and 4M. -Besides, it has the same function as Laing  D5 in realizing different performance from 5-20W via the knob on pump bottom for Changing flow rate conveniently. More importantly, compared with Laing  D5 it is very prominent in the following points:
   1. Endure high temperature till 110°C;
   2. Endure high system pressure 10bar;
   3. Fully stainless steel pump head and chamber;
   4. More competitive prices than  Laing  D5 but better overall performance.







Advantages over solar pumps from SID and Laing D5
many of our clients also reflected application problems by using SID and Laing-D5 pumps, such as tempreature, MPPT max efficiency and so on. But they are very satisfied with ours till now since transition. Our TS5&TD5 solar pumps are developed by studying SID and Laing-D5 pumps first,

1.  Motor

2.  MPPT functions



Then optimize their weakness. For example, there exists tempreature issue due to spherical motor for Laing D5 pumps, and SID pumps do not have MPPT functions. Generally, our solar pumps have comprehend all advantages and optimize the advantages for supporting solar system at its max performance, and have been tested and applied in the market for a long time with nice feedback. I believe topsflo will be a great choice for you.

No.

Weakness

Improvement

1, Motor

tempreature issue due to spherical motor for Laing D5 pumps

High efficiency ECM brushless DC motor, reach clients’ requirements in long lifetime and over all performance.

2, MPPT function

SID pumps do not have MPPT functions

TD5 with MPPT function, can realize four powers, 5W, 10W, 15W, 25W automatically wuth hiest efficieny.

3, Structure&Design

SID&Laing D5

More reasonable and nicer-looking





Specification



Specifications:

No.

Keypoint

Figure

1

Wide range of working voltage

6V-24V DC/ mainly 17V

2

Max flow rate

25LPM/6.6GPM/ 25L per Min

3

Max water head

4M/ 13’

4

System pressure

Max 20 BAR

5

Temperature

110°C/230°F

6

Approved by

ISO9001&CE&RoHS&REACH





Item NO.Power Consumption
(W)
Max Head
(M @ 0L/min)
Max Flow
(L/min @ 0M)
TD5/PV-A17-2504-M
("M"  means optional mounting fixture)
 @   5W1.412
 @ 10W2.416.5
 @ 15W320
 @ 25W425





Performance



No.

Strengthness

1

24 hrs continuous work

2

Male 1/2” BSP or NBT connection

3

DC/ Battery/ solar PV powered

4

Dry-running protection, no self-priming

5

Over-voltage protection

6

Overload & Over current protection

7

Polarity protection

8

3 phase dc motor

9

Food grade

10

Static balance

11

Can endure High temperture 220°C~240°C shoortly







Application



• Solar Water Heating Systems    • Portable power supplies

•  Hot pump air conditioner        •  Air energy water heater

 Hot Water Circulation           •  Radiant Floor Heating

 Heat Transfer Applications      •  Cooling Systems

 Beer Brewing                  •  Food Liquid Transfer

 Hot water Transfer Pump for Home Brewing    •  Portable power supplies




Curve & Dimension
